NEC M651 65" 4K UHD 60Hz 8ms Commercial Display - New, Opened Box SKU: NEC-M651-OB
New
Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also allowing the modularity possibilities to customize their needs dependent on their application and use. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters – the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget.
- Industrial-strength, premium-grade panel with additional thermal protection, internal temperature sensors with self-diagnostics and fan-based technology, allow for 24/7 operation
- 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
- Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
- Accepts Intel® Smart Display Module Small or Large allowing for sleek all-in-one intelligence and interoperability in a small form factor setting by accepting Intel processor-based products and other peripherals directly into the displays
- Raspberry Pi Compute Module 4 allows for future proof expansion and NEC Mediaplayer support
- Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
- 500 cd/m2 brightness and HDR compatibilty will capture the attention of audience in almost any situation
- Integrated Media Player allows for audio, video or image playback via USB
- Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails
- Integrated Ambient Light Sensor allows the display to autmatically adjust its luminance based on external brightness conditions
- Energy Star 8.0 Certified Product
- Cisco Certified Display
(NEC-M651-OB)
Display
Panel Technology | IPS | Viewable Image Size | 65 " |
Aspect Ratio | 16:9 | Native Resolution | 3840x2160 |
Supported Resolutions | DIsplayPort: V1.2 (HDCP 1.3/2.2) VGA60, SVGA60, XGA60, SXGA60, UXGA60, WUXGA60, 1920 x 1080 (60Hz), 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 3840x2160 (24 Hz/25 Hz/30 Hz/50 Hz/60 Hz), 4096x2160 (24 Hz/25 Hz/30 Hz/50 Hz/60 Hz) HDMI (HDCP 1.4/2.2) VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60, WUXGA60, 1920x1080 (60 Hz), 1080p, 1080i, 720p@50 Hz/60 Hz, 576p@50 Hz, 480p@60 Hz, 576i@50 Hz, 480i@60 Hz, 3840x2160 (24 Hz/25 Hz/30 Hz/50 Hz (MODE2)/60 Hz (MODE2)), 4096x2160 (24 Hz/25 Hz/30 Hz/50 Hz (MODE2)/60 Hz (MODE2)) | Pixel Pitch | 0.37 mm |
Pixels Per Inch | 68 @ native resolution | Backlight Type | LED Edge-lit |
Brightness (typical) | 500 cd/m2 | Contrast Ratio (typical) | ≥8,000:1 (Out of the box conditions, local dimming ON) |
Viewing Angle (typical) | 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 | Response Time (Gray to Gray) | 8 ms |
Refresh Rate | 60Hz | Active Screen Area | 56.24 x 31.63 in. / 1428.5 x 803.5mm |
Orientation | Landscape/Portrait | Dimming Capability | Local Dimming Capable |
Displayable Colors | More than 1.08 billion (8-bit+FRC) | Color Temperature (Max) (°K) | 10000K |
Color Temperature (Min) (°K) | 2600K | Gamma (Typical) | Native, 2.2, 2.4, S-Gamma, DICOM, Programmable1, Programmable2, Programmable3 |
Synchronization Range
Horizontal (Analog/Digital) | Digital: 26.0 - 135.0kHz | Vertical | Digital: 23.0 - 86.0Hz |
Input Signal
Video | Digital TMDS / DisplayPort |
Signal Compatibility/Connectivity
PC Signal Compatibility | Yes | Macintosh Signal Compatibility | Yes |
Video | Digital TMDS / DisplayPort | External Control | LAN and RS232 In - Full external control capabilities |
Input Terminals
Digital: HDMI (2.0 x 2 with HDCP), DisplayPort (1.2 with HDCP) Audio: 3.5 Mini-Jack x2, DisplayPort Audio, HDMI Audio x3 External Control: RS-232C, LAN (100Mb), 3.5mm Mini-Jack (IR Remote) Data: USB 2.0 (Media Player) |
Output Terminals
Audio: 3.5mm Mini-Jack |
Power Consumption (typical)
On | 120W | ECO Mode Standby | <0.5W |
Network Standby | 0.5W | Power Consumption (max) | 150W (Brightness Max), 260W (Brightness Max, SDM Max, Volume Max) |
Power Savings Mode | 2 W |
Physical Specifications
Bezel Width (Left/Right, Top/Bottom) | 0.49 in./0.49 in., 0.47 in./0.61 in. : 12.5 mm/12.5 mm, 12 mm/15.6 mm | Dimensions (WxHxD)
Without stand: 57.4 x 32.9 x 2.5 in. / 1458.4 x 836.2 x 62.4 mm Shipping: 68.4 x 40.7 x 11.0 in. / 1736.0 x 1033.0 x 280.0mm |
|
Weight
Net Weight (without stand): 81.8 lbs. / 37.1 kg. Shipping: 108.7lbs. / 49.3kg |
VESA Hole Configuration | 400 x 400mm (M8 x 4-hole) |
Environmental Conditions
Operating Humidity | 20 - 80% | Operating Altitude | 9843 ft. / 3000m |
Storage Temperature | -4-140°F / -20-60°C | Storage Humidity | 10-80% |
Storage Altitude | 40,000 ft. / 12,192m |
Environmental Compliance
ENERGYSTAR | Energy Star 8.0 |
Limited Warranty (parts & labor)
3 years Advanced Exchange |
Additional Features
|
Accessories
Optional |
|
Cooling Method
Multiple integrated temperature sensors and fans for active cooling and real time temperature measuring to ensure that the display stays cool for extended runtimes |
SKU | NEC-M651-OB |
Barcode # | 659699714943 |
Brand | NEC |
Brand | NEC |
Type | Commercial Display |
Screen Size | 65" |
Model | M651 |
Shipping Cubic | 0.017794000m3 |
