The SB-3879 is a professional high performance video graphics scaler supporting seven (7) different inputs and output signal, HDMI™, VGA and S/ PDIF & Stereo Audio. The Inputs are comprised of 1x Composite Video & Audio, 1x S-Video & Audio, 1x Component Video & Audio, 1x VGA & Audio, 1x DVI & Audio, 1x DisplayPort and 1x HDMI™. The available output ports are 1x HDMI™, 1xVGA, 1x S/PDIF and 1x Stereo Audio. This scaler supports S-Video with 3D comb filter, HDMI™ 3D 1.4a formats, HDCP 1.3 Compliant. It is able to auto detects the video standard format of input signal from NTSC / PAL / SECAM system, and convert to high definition RGB digital HD signal.

The scaler supports full HDTV resolution data rates enabling 480i/p, 576i/P, 720p or 1080i/p formats, higher DVI resolution (1920x1200 ), HDMI™ 1080p- 60, DP (2550x1600) which is ideally for high definition 3D TV, HDTV, Plasma display or monitor applications. Control is provided via front panel buttons, RS- 232, Ethernet, or IR remote control (included). A RS-232 interface is provided for interfacing with third party controller. The windows-based control software package is included to provide complete control of the SB-3879 from a PC.

(SB-3879)

Scaler Type 7 in 2 out HDMI Video Scaler
Video Input Signal 1x Composite / 1x S-Video / 1x Component / 1x VGA / 1x DVI / 1x HDMI / 1x DP
Audio Input Signal Digital Audio (PCM), Stereo Audio
Video Output Signal 1x RGB, 1x HDMI
Audio Output Signal 1x S/PDIF Digital Audio, 1x Analog  Audio RH/LH, 1x HDMI Audio
3D Support 3D Video Format in HDMI 1.4a (225MHz)
Input Resolution 7.Input Resolution : Up to 1080p-60, 1920x1200, and DP 2560x1600
Output Resolution Up to 1080p-60 and 1920x1200
Source Status Automatic scanning of input/output status
HDCP Support DVI / HDMI / Display Port, compliant with HDCP 1.3
HDMI Compliance HDMI 1.4a receiver and transmitter
HDMI Cable Distance Max. 15 meters (~49 feet), depending on cable quality
Infrared Frequency 38KHz
Chassis Material Metal
IR Extend Distance 300 meters (~1000 feet) line cable via IR extender
Control IR remote control, RS-232, front panel push buttons
Dimension (WxDxH) 11.96" x 6.06" x 1.73" (304mm x 154mm x 44mm)
Rack Mount 19-inch panel type (1U-44L)
Power Supply Input 100 ~ 240 VAC, 50/60 Hz Output DC 12V, 3A
Safety Approvals CE, FCC, RoHS
Temperature 32°F - 100°F (0°C - 32°C)
Weight 1.4 kg / 3.09 lb
SKU SB-3879
Barcode # 659359372339
Brand Shinybow
Brand Shinybow
Type Video Scaler
Model SB-3879
Shipping Cubic 0.017794000m3
